3 – Minutes – CAD Siemens NX #010 – #018
Design Groups - Delayed Update
There are Feature Groups in Siemens NX but there are also Design Groups. You can structure your model with Design Groups. One advantage of Design Groups – you can update just the Design Group and leave the rest of your model at the current state. – Enjoy!
Boolean Operations with Design- & Featuregroups
You can use Design Groups & Feature Groups for Boolean Operations as well. The result is slightly different. Enjoy!
Break-Out Section view
The Break-Section View command is not in the ribbon anymore – you´ll find it here – Menu – Insert – View – Breakout – enjoy! Here you´ll find all about the breakoutview: https://youtu.be/3kfGkPtqeZY
View Positioning & Monochrome Drawing Display Command
In order to create a view like this, you need arangements, view positiioning and the Monochrome Drawing Display command. Enjoy!
3D Breakout Section View
You can use the Breakout Section View also for Isometric Views – Enjoy!
Raster Images - Import & Placement
Quite easy and convenient in Siemens NX – Import and Placement of Raster Images – enjoy!
Sketch Navigator - Show Moveable Objects & Fixed Height of Dimensions
So it completely escaped my attention, there has been a „new“ sketch navigator in Siemens NX for over a year, sorry for that! This is a short video with a first look, there will be more. Enjoy!
Sketch Navigator - Curves & Relations
The sketch navigator is a very useful tool and replaces the „old“ relations browser for good. This time I take a look at the Curves & Relations Tab – enjoy!
Sketch Navigator - External References & Issues
This time I take a look at the External References & Issues Tab. All in all this Sketch Navigator is a great tool. Enjoy!
